Cryogenic Liquid Air Separation Plant , Aquaculture Liquid Oxygen Production Plant 10000v

Cryogenic Liquid Air Separation Plant , Aquaculture Liquid Oxygen Production Plant 10000v supplier Cryogenic Liquid Air Separation Plant , Aquaculture Liquid Oxygen Production Plant 10000v supplier

Large Image :  Cryogenic Liquid Air Separation Plant , Aquaculture Liquid Oxygen Production Plant 10000v

Product Details:

Place of Origin:Zhejiang ,China ( mainland)
Brand Name:UIG
Certification:ISO 9001:2000
Model Number:KDO,KDN,KDON,KLN,KZO

Payment & Shipping Terms:

Minimum Order Quantity:1 SET
Price:Negotiation
Packaging Details:Sea Worthy Packing
Delivery Time:120 Days
Payment Terms:T/T ,L/C
Supply Ability:2-3 Sets Per Month
Detailed Product Description
Gox Purity: ≥99.7 Operating Pressur: 1.2Mpa,1Mpa
Power: 76-2800 KW Product Name: Cryogenic Air Separation Unit
Production Capacity: 50-3000 M3/hour Voltage: 380v,10000V

Cryogenic Liquid Air Separation Plant , Aquaculture Liquid Oxygen Production Plant 10000v





Quick Details:



Condition: new

Place of origin: China(mainland)

Brand name: UIG

Model number: KDO,KDN,KDON,KLN ,KZO,KZON SERIES

Production capacity:50-3000 m3/hour

Power :76-2800 KW

Voltage:380v,10000V

Certification: ISO 9001:2000

Warranty:1 year

Life:20 years with proper maintenance

After-sales service provided: Engineers available to service plants overseas

Usage: Industrial and medical (oxygen, liquid oxygen, nitrogen, liquid nitrogen)

UIG Air separation plants are designed for a vast range of capacities and products summarized below: FOR OXYGEN 99.7 % AND NITROGEN 99.999%



Specifications:



The main technical specifications of internal compression

Model contents

KZON-

50/50

KZON-

80/80

KZON-

100/100

KDON-

180-20

KDON-

300-50

KDON-

350-80

KDON-

500-150

KDON-

800-200

KDON-

1000-300

Gox flow

Nm³/h

50

80

100

180

300

350

500

800

100

Gox purity

%(O2)

≥99.7

≥99.7

≥99.7

≥99.7

≥99.7

≥99.7

≥99.7

≥99.7

≥99.7

Gan flow

Nm³/h

50

80

100

20

50

80

150

200

300

Gan purity

Ppm(O2)

≤10

≤10

≤10

≤10

≤10

≤10

≤10

≤10

≤10

Operating

 pressure

Mpa



1.2

1.2

1.2

1

1

1

1

1

1

Start-up time

hour

≤12

≤12

≤12

≤10

≤10

≤8

≤8

≤8

≤8

Operating

period

year

≥1

≥1

≥1

≥1

≥1

≥1

≥2

≥2

≥2



Oxygen filling (or booster) with liquid pump.



 The main technical specifications of external compression

Model contents

KDON-

80/200

KDON-

180/500

KDON-

350/800

KDON-

550-1000

KDON-

750-1500

KDON-

1000-2000

KDON-

1500-3000

KDON-

3000-3000

Gox flow

Nm³/h

80

180

350

550

750

1000

1500

3000

Gox purity

%(O2)

99.7

99.7

99.7

99.7

99.7

99.7

99.7

99.7

Gan flow

Nm³/h

200

500

800

1000

1500

2000

3000

3000

Gan purity

Ppm(O2)

≤10

≤10

≤10

≤10

≤10

≤10

≤10

≤10

Operating

 pressure

Mpa

0.65

0.63

0.62

0.6

0.58

0.58

0.56

0.56

Start-up time

hour

≤18

≤18

≤18

≤18

≤18

≤18

≤20

≤20

Operating

period

year

≥1

≥1

≥1

≥1

≥1

≥2

≥2

≥2



Oxygen filling(or booster)with oxygen compressor



Description:



Air enters the suction air filter and after being removed of dust and other mechanical contaminants in it, it is compressed to the pressure of 0.8MPa by air compressor. Air from the air compressor is cooled to 10℃ in the air precooling system and separated condensing water in water separator. after the water being separated its condensed water, taken into the molecular sieve adsorber for removing H2O, C2H2 and CO2. There are two molecular sieve adsorbers which operate on a staggered cycle, i.e. one vessel is adsorbing the contained impurities while the other is being reactivated by waste nitrogen from the rectifying column.

  Then the cleaned air is divided into two streams, one of them is taken into the rectifying column and cooled by the return waste nitrogen, oxygen,expander air through the main heat exchanger. The steam-liquid air mixture is taken into the lower column for rectifying, and herein the pure nitrogen from the top of the column enters into the evaporator-condenser and condensed by liquid oxygen from the upper column. A part of the liquid nitrogen is fed to the lower column as reflux. The other part after subcooling apart two parts after throttled. One part enters into the top of the upper column,other part enters storage tank as product.

  Another cleaned stream is compressed in booster end of the booster expansion turbine, then enters the main heat exchanger.  air from the middle and cold end of the main heat exchanger enter into the turbine expansion to generate most refrigeration for need of the plant's operation. After the expanded air return to heat exchange.

    The LOX is drawn from oxygen side of the evaporator-condenser, some of them enters storage tank as product.

    The waste nitrogen from the top of the upper column is warmed up, it goes to the regeneration molecular sieve adsorber.



Configuration features:



The plant is of full low-pressure flow expansion process, using molecular sieve purification system, air bearing turbo-expander and aluminum plate-fin type heat exchanger which greatly enhance the stability, security and reliable of operation.

The fractionating column adopts aluminum sieve plate column, whose plate rectification achieves the best effect after being precision calculated and manufactured by us, so the height of column is reduced. The oxygen & nitrogen recovery ratios of the column are high and the output regulating range is large.

The units of the whole plant are reasonable and the occupation area of the plant is small. It can be operated easily and various data can be monitored by on-line digital indicator.



Applications:



 The products of the company cover the fields of metallurgy, petrochemical industry, electronics, machinery, construction material, Medicine ,New materials which have been well received all over the country and also been supplied to many Asian and African countries (Russia, Kazakhstan, Tajikistan, India, Bangladesh, Thailand, Philippines, North Korea, Mongolia, Equatorial Guinea, Botswana, Zambia, Angola, Tanzania) .The main products are: the medium and small size oxygen nitrogen plants, liquid oxygen and liquid nitrogen plants, oxygen and nitrogen liquefaction plants, high purity nitrogen generators.

Cryogenic Liquid Air Separation Plant , Aquaculture Liquid Oxygen Production Plant 10000v

Competitive Advantage:



1)Adopted to produce Oxygen and Nitrogen

2)The air as mostly in Liquid state

3)Easy to install



Cryogenic air separation unit,Cryogenic oxygen plant,Cryogenic liquid oxygen plant,Cryogenic nitrogen plant,Cryogenic liquid nitrogen plant,Cryogenic air separation equipment,Cryogenic oxygen machine,Cryogenic oxygen equipment,Cryogenic nitrogen machine,Cryogenic nitrogen equipment
