Product Details:
Payment & Shipping Terms:
|
| Operating Pressure: | 1.2 Mpa | Gan Flow: | 50,60,80,100m³/h |
|---|---|---|---|
| Gan Purity: | 99.999% | Gox Flow: | 50m³/h |
| Gox Purity: | 99.6% | Operating Pressur: | 1.2Mpa,1Mpa |
| Product Name: | Cryogenic Air Separation Unit | ||
| High Light: | cryogenic nitrogen generation plant,industrial nitrogen generator |
||
Energy Saving Liquid Oxygen And Nitrogen Air Separation Unit / Machine 80 nm³/h
Internal compression air separation plants:
Air-Compressed-Precooling-Purifier-Rectification-heart exchanger (low pressure liquid)-Liquid oxygen pump(pressurized liquid oxygen)-oxygen vaporizer - oxygen cylinders
The main technical specifications of internal compression
|
Model contents |
KZON- 50/50 |
KZON- 80/80 |
KZON- 100/100 |
KDON- 180-20 |
KDON- 300-50 |
KDON- 350-80 |
KDON- 500-150 |
KDON- 800-200 |
KDON- 1000-300 |
|
|
Gox flow |
Nm³/h |
50 |
80 |
100 |
180 |
300 |
350 |
500 |
800 |
100 |
|
Gox purity |
％(O2) |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
≥99.6 |
|
Gan flow |
Nm³/h |
50 |
80 |
100 |
20 |
50 |
80 |
150 |
200 |
300 |
|
Gan purity |
Ppm(O2) |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
|
Operating pressure |
Mpa |
1.2 |
1.2 |
1.2 |
1 |
1 |
1 |
1 |
1 |
1 |
|
Start-up time |
hour |
≤12 |
≤12 |
≤12 |
≤10 |
≤10 |
≤8 |
≤8 |
≤8 |
≤8 |
|
Operating period |
year |
≥1 |
≥1 |
≥1 |
≥1 |
≥1 |
≥1 |
≥2 |
≥2 |
≥2 |
