Product Details:
Payment & Shipping Terms:
|
| Gan Flow: | 20Nm³/h | Gox Flow: | 50 M³/h,60 M³/h,80 M³/h,100 M³/h |
|---|---|---|---|
| Gox Purity: | ≥99.7% | Operating Pressur: | 1.2Mpa |
| Power: | 200-1000 KW | Product Name: | Air Separation Plant |
| Production Capacity: | 180-1000 M3/hour | Voltage: | 380v,400V,440V |
| High Light: | nitrogen gas generator,cryogenic nitrogen generation plant |
||
Medical Air Gas Separation Unit / Plant , Liquid Oxygen Generating Machine 1000KW
Quick Details:
Condition:new
Place of origin:China(mainland)
Brand name:UIG
Model number:KDO, KDON SERIES
Production capacity:180-1000 m3/hour
Power :200-1000 KW
Voltage:380v,400V,440V
Certification:ISO 9001:2000
Warranty:1 year
Life:20 years with proper maintenance
After-sales service provided: Engineers available to service plants overseas
Usage: medical (oxygen, liquid oxygen,nitrogen,liquid nitrogen)
UIG Air separation plants are designed for a vast range of capacities and products summarized below: FOR OXYGEN 99.7 % AND NITROGEN 99.999%
Specifications:
|
Model contents |
KZO-50 |
KZO-60 |
KZO-80 |
KZO-100 |
|
O2 flow |
50 m³/h |
60 m³/h |
80 m³/h |
100 m³/h |
|
O2 purity |
≥99.7% |
≥99.7% |
≥99.7% |
≥99.7% |
|
O2 pressure |
15 -25MPA |
15 -25MPA |
15 -25MPA |
15 -25MPA |
|
Operating pressure |
1.2Mpa |
1.2Mpa |
1.2Mpa |
1.2Mpa |
|
Start-up time |
8-12 Hours |
8-12 Hours |
8-12 Hours |
8-12 Hours |
|
Operating period |
≥1 Years |
≥1 Years |
≥1 Years |
≥1 Years |
|
Model contents |
KDON- |
KDON- |
KDON- |
KDON- |
KDON- |
KDON- |
|
|
Gox flow |
Nm³/h |
180 |
300 |
350 |
500 |
800 |
100 |
|
Gox purity |
％(O2) |
≥99.7 |
≥99.7 |
≥99.7 |
≥99.7 |
≥99.7 |
≥99.7 |
|
Gan flow |
Nm³/h |
20 |
50 |
80 |
150 |
200 |
300 |
|
Gan purity |
Ppm(O2) |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
|
Operating pressure |
Mpa |
1 |
1 |
1 |
1 |
1 |
1 |
|
Start-up time |
hour |
≤10 |
≤10 |
≤8 |
≤8 |
≤8 |
≤8 |
|
Operating period |
year |
≥1 |
≥1 |
≥1 |
≥2 |
≥2 |
≥2 |
Oxygen filling (or booster) with liquid pump.
Description:
China Medical oxygen GB8982-1998
|
Name |
Index |
|
Oxygen content,% (V/V) ≥ |
99.5 |
|
Water content,(20℃101.3kpa(760mmHg)),g/m3 ≤ |
0.07 |
|
Carbon dioxide content,% (V/V) ≤ |
0.01 |
|
Carbon monoxide content |
GB8982,Chapter5 |
|
Gaseous acid and alkali content |
GB8982,Chapter6 |
|
Ozone and other gaseous oxide content |
GB8982,Chapter7 |
|
Odor |
Odorless |
Medical and biological technology: Supply breathing, used to ischemia, hypoxia or anaerobic environment.
Features :
1. The raw material used by the oxygen generator is air and the only cost is electricity; A low consumption results in low operating costs.
2. The process of oxygen generation is controlled by pneumatic valves, giving a compact structure, reliability and convenient maintenance.
3. Safe and reliable operation under normal temperatures and low pressure.
4. The machine can be operated anywhere with domestic lighting supply conditions.
Easy operation
Continuous and stable performance.
5. The quality of the oxygen generating capability of the unit is unaffected by climatic conditions and operates well in cold temperatures and at high altitude. (refer to operating temperature)
Use & applied range
(1) Use: Oxygen therapy or oxygen health care for hospitals and home health care uses.
(2) Applied range:
A. Oxygen treatment for respiratory diseases such as bronchitis, bronchial asthma (chronic obstructive pulmonary disease, COPD).
B. Oxygen treatment for cardiovascular diseases such as coronary heart disease, heart functional disorder (heart failure)
C. Oxygen treatment for cerebrovascular diseases such as cerebral anoxemia, cerebral infarct, cerebral megrim.
D. Oxygen treatment for altitude anoxia and mountain sickness such high altitude pulmonary edema, high altitude heart disease.
E. Oxygen treatment for other common diseases such as diabetes, paroxysmal deaf air conditioning sickness.
F. Oxygen supplement for pregnant women, fetus and infant.
Applications:
we supplied to many countries (Russia, Kazakhstan, Tajikistan, India, Bangladesh, Thailand, Philippines, North Korea, Mongolia, Equatorial Guinea, Botswana, Zambia, Angola, Tanzania) .
Competitive Advantage:
Oxygen of high purity and very stable, meet and exceed technical indicators of GB8982-1998.
Medical air separation plant,Medical oxygen plant,Medical liquid oxygen plant,Medical air separation equipment,Medical oxygen equipment,Medical oxygen machine,Hospital air separation plant,Hospital air separation plant,Hospital air separation equipment,Hospital oxygen plant.
