| Gan Flow: | 20,50,80,100,150,200,300Nm³/h | Gan Purity: | ≤10Ppm(O2) |
|---|---|---|---|
| Gox Flow: | 180,300,350,500,800Nm³/h | Gox Purity: | ≥99.7% |
| Operating Pressure: | 1Mpa | Power: | 200-1000 KW |
| Product Name: | Air Separation Unit | Production Capacity: | 180-1000 M3/hour |
| Voltage: | 380v,400V,440V | ||
| High Light: | Oxygen Generating Plant,Oxygen nitrogen plant |
||
180 - 1000 m³ / hour External Compression Air Separation Plant / Equipment
Quick Details:
Condition: new
Place of origin: China(mainland)
Brand name: UIG
Model number: KDO, KDON, SERIES
Production capacity:180-1000 m3/hour
Power :200-1000 KW
Voltage:380v,400V,440V
Certification: ISO 9001:2000
Warranty:1 year
Life:20 years with proper maintenance
After-sales service provided: Engineers available to service plants overseas
Usage: Industrial and medical (oxygen, nitrogen)
UIG Air separation plants are designed for a vast range of capacities and products summarized below: FOR OXYGEN 99.7 % AND NITROGEN 99.999%
Specifications:
Two compression methods:
1)Internal compression air separation plants:
|
Model contents |
KDON- |
KDON- |
KDON- |
KDON- |
KDON- |
KDON- |
|
|
Gox flow |
Nm³/h |
180 |
300 |
350 |
500 |
800 |
100 |
|
Gox purity |
％(O2) |
≥99.7 |
≥997 |
≥99.7 |
≥99.7 |
≥99.7 |
≥99.7 |
|
Gan flow |
Nm³/h |
20 |
50 |
80 |
150 |
200 |
300 |
|
Gan purity |
Ppm(O2) |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
|
Operating pressure |
Mpa |
Operating pressure |
1 |
1 |
1 |
1 |
1 |
|
Start-up time |
hour |
≤10 |
≤10 |
≤8 |
≤8 |
≤8 |
≤8 |
|
Operating period |
year |
≥1 |
≥1 |
≥1 |
≥2 |
≥2 |
≥2 |
Oxygen filling (or booster) with liquid pump.
2)External compression air separation plants:
Air-Compressed-Precooling-Purifier-Rectification-heart exchanger (low pressure gas)-oxygen storage-oxygen compressor(pressurized oxygen)-oxygen cylinders
|
Model contents |
KDON- |
KDON- 350/800 |
KDON- |
KDON- |
KDON- |
|
|
Gox flow |
Nm³/h |
180 |
350 |
550 |
750 |
1000 |
|
Gox purity |
％(O2) |
99.6 |
99.6 |
99.6 |
99.6 |
99.6 |
|
Gan flow |
Nm³/h |
500 |
800 |
1000 |
1500 |
2000 |
|
Gan purity |
Ppm(O2) |
≤10 |
≤10 |
≤10 |
≤10 |
≤10 |
|
Operating pressure |
Mpa |
0.63 |
0.62 |
0.6 |
0.58 |
0.58 |
|
Start-up time |
hour |
≤14 |
≤16 |
≤16 |
≤18 |
≤18 |
|
Operating period |
year |
≥1 |
≥1 |
≥1 |
≥1 |
≥2 |
Oxygen filling(or booster)with oxygen compressor.
Description:
Oxygen filling (or booster) with liquid pump.
Internal compression air separation plants:
Air-Compressed-Precooling-Purifier-Rectification-heart exchanger (low pressure liquid)-Liquid oxygen pump(pressurized liquid oxygen)-oxygen vaporizer - oxygen cylinders
Oxygen filling (or booster) with liquid pump.
External compression air separation plants:
Air-Compressed-Precooling-Purifier-Rectification-heart exchanger (low pressure gas)-oxygen storage-oxygen compressor(pressurized oxygen)-oxygen cylinders
Applications:
we supplied to many countries (Russia, Kazakhstan, Tajikistan, India, Bangladesh, Thailand, Philippines, North Korea, Mongolia, Equatorial Guinea, Botswana, Zambia, Angola, Tanzania) .
Competitive Advantage:
1. No gas loss and high yield
2.Very simple and safe to operate
3. Low power consumption
4. Low Working Pressure
5. Low Operating Cost
6. Low Maintenance Cost
7. The life span is over 20 years
8. Engineers available to service machinery overseas
9. All gas and liquid plants are optimized to meet customer-specific site requirements
Small-medium size air separation unit,Small-medium size oxygen plant,Small-medium size liquid oxygen plant,Small-medium size nitrogen plant,Small-medium size liquid nitrogen plant,Small-medium size air separation plant,Small-medium size oxygen machine,Small-medium size oxygen equipment,Small-medium size nitrogen machine,Small-medium size nitrogen equipment
