Product Details:
Payment & Shipping Terms:
|
N2 Flow: | 15,30,40,60,80,100,120,180L/h | N2 Purity: | ≤3Ppm(o2),≤1Ppm(o2) |
---|---|---|---|
N2 Pressure: | As The User Requires | Power: | 200-1000 KW |
Product Name: | Nitrogen Generating Equipment | Production Capacity: | 180-1000 M3/hour |
Usage: | Industrial And Medica(Nitrogen) | Voltage: | 380v,400V,440V |
High Light: | Oxygen Generating Plant,Oxygen nitrogen plant |
Low Power Cryogenic Liquid Nitrogen Gas Plant , Small-Medium Air Separation Unit
Quick Details:
Condition: new
Place of origin: China(mainland)
Brand name: UIG
Model number: KDO, KDON, SERIES
Production capacity:180-1000 m3/hour
Power :200-1000 KW
Voltage:380v,400V,440V
Certification: ISO 9001:2000
Warranty:1 year
Life:20 years with proper maintenance
After-sales service provided: Engineers available to service plants overseas
Usage: Industrial and medical (oxygen, nitrogen)
UIG Air separation plants are designed for a vast range of capacities and products summarized below: FOR OXYGEN 99.7 % AND NITROGEN 99.999%
Specifications:
Air separation plants(pure nitrogen and high pure nitrogen)
Model contents |
KDN- 400/15Y |
KDN- 800/40Y |
KDN- 1000-40Y |
KDN- 1600-60Y |
KDN- 2000-80Y |
KDN- 2400-100Y |
KDN- 3000-120Y |
KDN- 4500/180Y |
|
N2 flow |
Nm³/h |
500 |
800 |
1000 |
1600 |
2000 |
2400 |
3000 |
4500 |
LN2 flow |
L/h |
15 |
30 |
40 |
60 |
80 |
100 |
120 |
180 |
N2 purity |
Ppm(o2) |
≤3 |
≤3 |
≤3 |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
N2 pressure |
Mpa |
as the user requires |
|||||||
Start-up time |
hour |
~12 |
~12 |
~14 |
~16 |
~16 |
~18 |
~18 |
~20 |
Operating period |
year |
≥1 |
≥1 |
≥2 |
≥2 |
≥2 |
≥2 |
≥2 |
≥2 |
Description:
Oxygen filling (or booster) with liquid pump.
Internal compression air separation plants:
Air-Compressed-Precooling-Purifier-Rectification-heart exchanger (low pressure liquid)-Liquid oxygen pump(pressurized liquid oxygen)-oxygen vaporizer - oxygen cylinders
Oxygen filling (or booster) with liquid pump.
External compression air separation plants:
Air-Compressed-Precooling-Purifier-Rectification-heart exchanger (low pressure gas)-oxygen storage-oxygen compressor(pressurized oxygen)-oxygen cylinders
Applications:
we supplied to many countries (Russia, Kazakhstan, Tajikistan, India, Bangladesh, Thailand, Philippines, North Korea, Mongolia, Equatorial Guinea, Botswana, Zambia, Angola, Tanzania) .
Competitive Advantage:
1. No gas loss and high yield
2.Very simple and safe to operate
3. Low power consumption
4. Low Working Pressure
5. Low Operating Cost
6. Low Maintenance Cost
7. The life span is over 20 years
8. Engineers available to service machinery overseas
9. All gas and liquid plants are optimized to meet customer-specific site requirements
