Liquid Cryogenic Air Separation Plant / Unit 380V ASU Industrial Nitrogen Generator

Large Image :  Liquid Cryogenic Air Separation Plant / Unit 380V ASU Industrial Nitrogen Generator

Product Details:

Place of Origin:Zhejiang ,China ( mainland)
Brand Name:UIG
Certification:ISO 9001:2000
Model Number:KDO,KDN,KDON,KLN

Payment & Shipping Terms:

Minimum Order Quantity:1 SET
Price:Negotiation
Packaging Details:Sea Worthy Packing
Delivery Time:120 Days
Payment Terms:T/T ,L/C
Supply Ability:2-3 Sets Per Month
Detailed Product Description
Gox Purity: 99.6% Operating Pressur: 0.08 MPA
Power: 100-1800 KW Product Name: Cryogenic Air Separation Unit
Production Capacity: 50-1000 M3/hour Voltage: 380v,10000V

Liquid Cryogenic Air Separation Plant / Unit 380V ASU Industrial Nitrogen Generator





Quick Details:



Condition: new

Place of origin: China(mainland)

Brand name: UIG

Model number: KDO,KDN,KDON,KLN SERIES

Production capacity:50-1000 m3/hour

Power :100-1800 KW

Voltage:380v,10000V

Certification: ISO 9001:2000

Warranty:1 year

Life:20 years with proper maintenance

After-sales service provided: Engineers available to service plants overseas

Usage: Industrial and medical (oxygen, liquid oxygen, nitrogen, liquid nitrogen)

UIG Air separation plants are designed for a vast range of capacities and products summarized below: FOR OXYGEN 99.7 % AND NITROGEN 99.999%



Specifications:



LO2   flow

100  L/h

200  L/h

300  L/h

500  L/h

800  L/h

LO2   purity

99.6%

99.6%

99.6%

99.6%

99.6%

LOX   pressure

0.08 MPA

0.08 MPA

0.08 MPA

0.08 MPA

0.08 MPA

LN2   flow

(100 L/h )

(200  L/h )

(300  L/h )

(500  L/h )

(800  L/h )

LN2   purity

99.999%

99.999%

99.999%

99.999%

99.999%

LN2   pressure

0.08 MPA

0.08 MPA

0.08 MPA

0.08 MPA

0.08 MPA

Start-up  time

5-8 Hours

5-8  Hours

5-8 Hours

5-8  Hours

5-8  Hours

Operating period

≥2 Years

≥2  Years

≥2  Years

≥2  Years

≥2  Years



Process:



Air→ Air compressor → Pre-cooler → Purifier →Rectification column and Turbo-expander →liquid oxygen tank or liquid nitrogen tank



Description:



Configuration features:

The plant is of full low-pressure flow expansion process, using molecular sieve purification system, air bearing turbo-expander and aluminum plate-fin type heat exchanger which greatly enhance the stability, security and reliable of operation.

The fractionating column adopts aluminum sieve plate column, whose plate rectification achieves the best effect after being precision calculated and manufactured by us, so the height of column is reduced. The oxygen & nitrogen recovery ratios of the column are high and the output regulating range is large.

The units of the whole plant are reasonable and the occupation area of the plant is small. It can be operated easily and various data can be monitored by on-line digital indicator.



Applications:



we supplied to мany countries (Russia, Kazakhstan, Tajikistan, India, Bangladesh, Thailand, Philippines, North Korea, Mongolia, Equatorial Guinea, Botswana, Zambia, Angola, Tanzania) .

Liquid Cryogenic Air Separation Plant / Unit 380V ASU Industrial Nitrogen Generator



Competitive Advantage:



Higher economic efficiency, good quality, lower transportation cost, better performance price, safety and convenience.



Liquid air separation unit,Liquid oxygen plant,Liquid nitrogen plant,Liquid air separation equipment,Liquid oxygen machine,Liquid oxygen equipment,Liquid nitrogen machine,Liquid nitrogen equipment
