Industrial Cryogenic Air Separation Plant , Nitrogen Production Plant / Unit 350 nm³/h

Industrial Cryogenic Air Separation Plant , Nitrogen Production Plant / Unit 350 nm³/h supplier Industrial Cryogenic Air Separation Plant , Nitrogen Production Plant / Unit 350 nm³/h supplier

Large Image :  Industrial Cryogenic Air Separation Plant , Nitrogen Production Plant / Unit 350 nm³/h

Product Details:

Place of Origin:Zhejiang ,China ( mainland)
Brand Name:UIG
Certification:ISO 9001:2000
Model Number:KDO,KDN,KDON,KLN,KZO

Payment & Shipping Terms:

Minimum Order Quantity:1 SET
Price:Negotiation
Packaging Details:Sea Worthy Packing
Delivery Time:120 Days
Payment Terms:T/T ,L/C
Supply Ability:2-3 Sets Per Month
Detailed Product Description
Gan Flow: 50,80,150,200,300Nm³/h Gan Purity: ≤10
Gox Flow: 50 M³/h,60 M³/h,80 M³/h,100 M³/h Gox Purity: ≥99.7%
Operating Pressur: 1.2Mpa|1Mpa Power: 76-2800 KW
Product Name: Air Separation Plant Production Capacity: 50-3000 M3/hour
Voltage: 380v,10000V

Industrial Cryogenic Air Separation Plant , Nitrogen Production Plant / Unit 350 nm³/h





Quick Details:



Condition: new

Place of origin: China(mainland)

Brand name: UIG

Model number: KDO,KDN,KDON,KLN ,KZO,KZON SERIES

Production capacity:50-3000 m3/hour

Power :76-2800 KW

Voltage:380v,10000V

Certification: ISO 9001:2000

Warranty:1 year

Life:20 years with proper maintenance

After-sales service provided: Engineers available to service plants overseas

Usage: Industrial and medical (oxygen, liquid oxygen, nitrogen, liquid nitrogen)

UIG Air separation plants are designed for a vast range of capacities and products summarized below: FOR OXYGEN 99.7 % AND NITROGEN 99.999%



Specifications:



The main technical specifications of internal compression

Model contents

KZON-

50/50

KZON-

80/80

KZON-

100/100

KDON-

180-20

KDON-

300-50

KDON-

350-80

KDON-

500-150

KDON-

800-200

KDON-

1000-300

Gox flow

Nm³/h

50

80

100

180

300

350

500

800

100

Gox purity

%(O2)

≥99.7

≥99.7

≥99.7

≥99.7

≥99.7

≥99.7

≥99.7

≥99.7

≥99.7

Gan flow

Nm³/h

50

80

100

20

50

80

150

200

300

Gan purity

Ppm(O2)

≤10

≤10

≤10

≤10

≤10

≤10

≤10

≤10

≤10

Operating

 pressure

Mpa



1.2

1.2

1.2

1

1

1

1

1

1

Start-up time

hour

≤12

≤12

≤12

≤10

≤10

≤8

≤8

≤8

≤8

Operating

period

year

≥1

≥1

≥1

≥1

≥1

≥1

≥2

≥2

≥2



Oxygen filling (or booster) with liquid pump.



 The main technical specifications of external compression

Model contents

KDON-

80/200

KDON-

180/500

KDON-

350/800

KDON-

550-1000

KDON-

750-1500

KDON-

1000-2000

KDON-

1500-3000

KDON-

3000-3000

Gox flow

Nm³/h

80

180

350

550

750

1000

1500

3000

Gox purity

%(O2)

99.7

99.7

99.7

99.7

99.7

99.7

99.7

99.7

Gan flow

Nm³/h

200

500

800

1000

1500

2000

3000

3000

Gan purity

Ppm(O2)

≤10

≤10

≤10

≤10

≤10

≤10

≤10

≤10

Operating

 pressure

Mpa

0.65

0.63

0.62

0.6

0.58

0.58

0.56

0.56

Start-up time

hour

≤18

≤18

≤18

≤18

≤18

≤18

≤20

≤20

Operating

period

year

≥1

≥1

≥1

≥1

≥1

≥2

≥2

≥2



Oxygen filling(or booster)with oxygen compressor



The Plant uses normal temperature molecular sieve adsorption, medium pressure booster expansion reflux flow.

Raw air is sucked from the atmosphere,It is going through filter for removal of dust and mechanical impurities.,then it is compressed to a certain degree by single stage screw compressor,via end stage cooler, air pre-cooling system, the air is cooled to approx. 8℃. After water separation moisture is separated in water separator and then it goes to purifier for removal of moisture, CO2, C2H2 and hydrogen dioxide.

Then most part of air enters main heat exchanger to be cooled to saturated tempt. and partly is liquefied to the lower part of lower column; another part of air is compressed to a certain degree through two stage compression booster, via end stage cooler enters into oxygen heat exchanger to be cooled to be near saturated temperature, then after throttle goes to lower column. Through lower column pre-distillation we can get enriched oxygen liquid air from the bottom of the column. After cooling through sub-cooler,after throttled it goes to the middle part of upper column as reflux liquid for rectification. WN is obtained from the top of lower column, after condensed through condenser-evaporator, a part of WN is used as rectification reflux liquid for lower column; another part after cooling through sub-cooler and after throttling goes to the top of upper column as rectification reflux liquid. Pure liquid oxygen is obtained from the bottom of upper column, and it is condensed by condenser-evaporator. Liquid oxygen is abstracted from the bottom after cooling through sub-cooler, then it goes to LOX pump to be pressurized. It is evaporated in O2 heat exchanger and is reheated to normal tempt and then directly goes to oxygen filling ramp for filling of cylinders.

WN from the top of upper column goes through sub-cooler, the ower part of main heat exchanger to be reheated to a certain tempt. Then it goes to expansion turbine to create cold and returns to sub-cooler and main heat exchanger again to be reheated to normal tempt. A part of it passes to purifier as regenerating gas resource and another part goes to be vented partly.





Description:



High production capacity, high purity, low power consumption, produce Nitrogen, Oxygen .

More choice in designation

As for the big production capacity and high purity, cryogenic air separation plant is now wide used in steel factory, food making, metal welding and cutting etc.

Our cryogenic air separation plants produce oxygen, nitrogen  efficiently and safely every day.

How It Works

The process begins with the intake of huge volumes of air from the atmosphere. The air is compressed and purified before entering the cryogenic equipment package. The air is cooled to about -300° F (-185° C) and then, relying on different boiling points, separated into its elemental components in the form of liquid oxygen and nitrogen.

We help to design and manufacture Cryogenic air separation plant of production capacity from 50cbm ~ 2000 cbm.

UIG cryogenic system components include:

An air filter

An air compressor

An air pre-purifier

An separation tower / insulated package containing cryogenic equipment (cold box)

A turbine expansion engine





Applications:



we supplied to many countries (Russia, Kazakhstan, Tajikistan, India, Bangladesh, Thailand, Philippines, North Korea, Mongolia, Equatorial Guinea, Botswana, Zambia, Angola, Tanzania) .

Industrial Cryogenic Air Separation Plant , Nitrogen Production Plant / Unit 350 nm³/h

Industrial Cryogenic Air Separation Plant , Nitrogen Production Plant / Unit 350 nm³/h



Competitive Advantage:



1, No gas loss and high yield

2, Very simple and safe to operate

3, Low power consumption

4, Low Working Pressure

5, Low Operating Cost

6, Low Maintenance Cost

7, The life span is over 20 years

8, Engineers available to service machinery overseas

9, All gas and liquid plants are optimized to meet customer-specific site requirements
